| Place of Origin: | China |
|---|---|
| Brand Name: | New-Era |
| Certification: | ISO9001 ISO14001 TS16949 |
| Model Number: | DIN17230 |
| Minimum Order Quantity: | 5 tons |
| Price: | Negotiation |
| Packaging Details: | packing in standard seaworthy packages. |
| Delivery Time: | 45days |
| Supply Ability: | 2000tons per month |
| Application: | Ball And Roller Bearing | Materials: | 100Cr2/100Cr6/100CrMn6/100CrMo73 |
|---|---|---|---|
| Grain Size: | Min ASTM 8 | Process: | Cold Drawn, Cold Rolled |
| Size: | OD:10-200mm;WT: 2-15mm | Standard: | DIN17230 Ball And Roller Steel |
| Product Name: | Cold Finished Seamless Bearing Steel Tubing | Heat-treament: | Stress Released Or Spheroidized Annealled |
| High Light: | din 17230 cold drawn seamless tube,100cr2 cold drawn seamless tube,roller bearing cds seamless tube |
||
The material standard:DIN17230 ball and roller bearing steel
Steel Grade:100Cr2,100Cr6,100CrMn6,100CrMo7,17MnCr5,19MnCr5,Cf54,43CrMo4,etc.
Delivery Condition: +C, +LC, +SR, +A, +N
Production Size Range:
OD: 10-210mm
WT: 2-30mm
Length: 2-5.8m
Applications:100Cr2,100Cr6,100CrMn6,100CrMo7,100CrMo73/17MnCr5,19MnCr5,Cf54,43CrMo4
for industry ball and roller bearing,Automotive bearing steel,producing by cold drawn seamless
tubes and cold rolled steel pipes.
Chemical compostions:
| Steel Grade | C(％) | Si(％) | Mn(％) | P(％) | S(％) | Cr(％) | Mo(%) |
| 100Cr2/1.3501 | 0.90～1.05 | 0.15-0.35 | 0.25～0.45 | ≤0.035 | ≤0.025 | 0.40～0.60 | ≤0.25 |
| 100Cr6/1.3505 | 0.90～1.05 | 0.15-0.35 | 0.25～0.45 | ≤0.035 | ≤0.025 | 1.35～1.65 | ≤0.25 |
| 100CrMo7/1.3537 | 0.90～1.05 | 0.20-0.40 | 0.25～0.45 | ≤0.035 | ≤0.025 | 1.65～1.95 | 0.15-0.25 |
| 100CrMo7 3/1.3536 | 0.90～1.05 | 0.20-0.40 | 0.60～0.80 | ≤0.035 | ≤0.025 | 1.65～1.95 | 0.20-0.35 |
| Cold drawn and Cold rolled bearing tubes tolerance control level | |||
| Outer Diameter | Diameter Tolerance | Outer Diameter | Diameter Tolerance |
| (mm) | (mm) | (mm) | (mm) |
| ≤12.70 | ±0.08 | >50.80～63.5 | ±0.25 |
| 12.7～25.40 | ±0.10 | >63.50～76.20 | ±0.30 |
| >25.4～38.10 | ±0.15 | >76.20～101.60 | ±0.40 |
| >38.1～50.80 | ±0.20 | >101.60～203.20 | ±0.50 |
| Remark:Tolrance on outer diameter and Inner diameter,wall thickness can be specified by customer requested |
|||
Bearing and Gearing Steel Tube Characteristic:
High strength
High-precision
Good Surface Quality
Stable quality
Smooth Roughness
Production Processs:
Seamless Cold Drawn or Seamless Cold Rolled + Heat Treatment or Stress released control
