SAE4130 Seamless Mechanical Tubing Cold Drawn
Basic Properties
Place of Origin:
China
Brand Name:
New Era
Certification:
ISO9001
Model Number:
ASTM A519
Trading Properties
Minimum Order Quantity:
3 tons
Price:
Negotiation
Payment Terms:
T/T
Supply Ability:
3000 tons/month
Product Summary
SAE4130 Seamless Mechanical Tubing ASTM A519 SAE4130 Seamless Steel Tubes Alloy Seamless Steel Tube SAE4130 Material:SAE1010, SAE1020, SAE4130 Size Range: OD: 6-168mm, WT: 1-30mm, Length: 5.8m/6m, maximal 11.8m Delivery Condition: CW, SR, A, N Stable Quality with Comeptitive Price. Stress Relieved ...
Product Details
Highlight:
SAE4130 Seamless Mechanical Tubing
,Cold Drawn Seamless Mechanical Tubing
,SAE4130 Alloy Steel Seamless Pipes
Product Name:
Seamless Mechanical Tubing
Delivery Condition:
HR, CW, SR, A, N
OD Size:
6-156mm
WT Size:
1-30mm
Material:
1010, 1020, 1026, 1045, 4130
Application:
SAE4130
Production Process:
Cold Drawn Or Cold Rolled
Heat Treatment:
SR，A，N
Product Description
SAE4130 Seamless Mechanical Tubing
ASTM A519 SAE4130 Seamless Steel Tubes
Alloy Seamless Steel Tube SAE4130
Material:SAE1010, SAE1020, SAE4130
Size Range: OD: 6-168mm, WT: 1-30mm, Length: 5.8m/6m, maximal 11.8m
Delivery Condition: CW, SR, A, N
Stable Quality with Comeptitive Price.
Stress Relieved Annealed Heat Treatment, Strength Relief heat treatment.
100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.
| Product Name | ASTM A519 SAE4130 Seamless Mechanial Tubing |
| Material | SAE4130, SAE1010, SAE1020, SAE4140, SAE1045 |
| Delivery Condition | HR, CW, SR, A, N |
| Standard | ASTM A519 |
| Application | Mechanical usage |
| Certificate | TS16949, ISO 9001 |
| HS code | 7304319000 |
| Delivery Time | 45 days |
| Pakcing | Bundles or Woodern Boxes |
| Grade | C | Mn | P ≤ | S ≤ | Si | Cr | Mo |
| 1010 | 0.08--0.13 | 0.30--0.60 | 0.40 | 0.05 | -- | -- | -- |
| 1020 | 0.18--0.23 | 0.30--0.60 | 0.40 | 0.05 | -- | -- | -- |
| 1026 | 0.22--0.28 | 0.60--0.90 | 0.40 | 0.05 | -- | -- | -- |
| 1045 | 0.43--0.50 | 0.60--0.90 | 0.40 | 0.05 | -- | -- | -- |
| 4130 | 0.28--0.33 | 0.40--0.60 | 0.04 | 0.04 | 0.15--0.35 | 0.80--1.10 | 0.15--0.25 |
| 4140 | 0.38--0.43 | 0.75--1.00 | 0.04 | 0.04 | 0.15--0.35 | 0.80--1.10 | 0.15--0.25 |
| Grade | Condition |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
HRB |
| 1020 | HR | 345 | 221 | 25 | 55 |
| CW | 483 | 414 | 5 | 75 | |
| SR | 448 | 345 | 10 | 72 | |
| A | 331 | 193 | 30 | 50 | |
| N | 379 | 234 | 22 | 60 | |
| 4130 | HR | 621 | 483 | 20 | 89 |
| SR | 724 | 586 | 10 | 95 | |
| A | 517 | 379 | 30 | 81 | |
| N | 621 | 414 | 20 | 89 |
Tags: Seamless Mechanical Tubing, SAE4130, Seamless Steel Tube, Alloy Steel Tubing, ASTM A519 Seamless Steel Tube, Alloy Steel Tube
