Sa334 Low Temperature Gr1 Seamless Boiler Tube
Basic Properties
Place of Origin:
China
Brand Name:
New Era
Certification:
ISO9001
Model Number:
SA334
Trading Properties
Minimum Order Quantity:
5 tons
Price:
Negotiation
Payment Terms:
T/T
Supply Ability:
3000 tons/month
Product Summary
SA334 Seamless and Welded Carbon and Alloy Steel Tubes for Low Temperature Service Gr1, Gr3,Gr6, Gr8,Gr11 etc Product Name SA334 Low Temperature Service Steel Tubes Material Gr1, Gr6, Gr8 etc Delivery Condition Heat Treatment Standard ASTM A334 Application Boiler, Heat Exchanger, Condensers and ...
Product Details
Highlight:
sa334 seamless boiler tube
,gr1 seamless boiler tube
,gr1 sa334 boiler tubes
Material:
Gr1, Gr6, Gr8, Etc
Delivery Condition:
Heat Treatment
OD Size:
12.7-127mm
WT Size:
1-12.7mm
Length:
5.8M,6M,11.8M
Application:
Low Temperature Service
Delivery Time:
45 Days
Production Process:
Seamless Or Welded
Product Description
SA334 Seamless and Welded Carbon and Alloy Steel Tubes for Low Temperature Service
Gr1, Gr3,Gr6, Gr8,Gr11 etc
| Product Name | SA334 Low Temperature Service Steel Tubes |
| Material | Gr1, Gr6, Gr8 etc |
| Delivery Condition | Heat Treatment |
| Standard | ASTM A334 |
| Application | Boiler, Heat Exchanger, Condensers and similar heat transfer apparatus |
| Certificate | ISO 9001 |
| HS code | 7304319000 |
| Delivery Time | 45 days |
| Packing | Bundles or Wooden Boxes |
The pipes are made by seamless or automatic welding process with no addition of no of filler metal in the welding operation.
All tubes Normalized by heating to a uniform temperature of not less than 845℃ and cool in air or in the cooling chamber of an atmosphere controlled furance.
Steel Material:
| Element | Compision, % | ||||||
| Gr1 | Gr3 | Gr6 | Gr7 | Gr8 | Gr9 | Gr11 | |
| C, max | 0.30 | 0.19 | 0.30 | 0.19 | 0.13 | 0.20 | 0.10 |
| Mn | 0.40-1.06 | 0.31-0.64 | 0.29-1.06 | 0.90 max | 0.90 max | 0.40-1.06 | 0.60 max |
| P, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 |
| S, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 |
| Si | - | 0.18-0.37 | 0.10 min | 0.13-0.32 | 0.13-0.32 | - | 0.35 max |
| Ni | - | 3.18-3.82 | - | 2.03-2.57 | 8.40-9.60 | 1.60-2.24 | 35.0-37.0 |
| Cr | - | - | - | - | - | - | 0.50 max |
| Cu | - | - | - | - | - | 0.75-1.25 | - |
| Co | - | - | - | - | - | - | 0.50 max |
| Mo | - | - | - | - | - | - | 0.50 max |
Tags: SA334 Boiler Steel Tubes, Steel Tubes for Low temperature service, SA334 Gr6, Boiler Tubes, SA334 Gr1, Low temperature Boiler Tube, Seamless Steel Tube, Boiler Tube, SA334 Boiler Tube
