St35 St45 St52 BK Cold Drawn Seamless Steel Pipe 140mm X 5mm
Basic Properties
Place of Origin:
China
Brand Name:
New Era
Certification:
ISO9001,TS16949
Model Number:
DIN2391
Trading Properties
Minimum Order Quantity:
10 tons
Price:
Negotiation
Payment Terms:
T/T
Supply Ability:
3000 tons/month
Product Summary
Cold Drawn Seamless Steel Pipe DIN2391 St35/St45/St52 BK Cold Worked Cold Drawn Steel Pipe O.D. Size: 6-256mm, W.T. Size: 1-30mm, Length: 5.8m/6m Fixed Length, or maximal 11.8m Random Length Delivery Condition: BK, BKW, BKS, GBK, NBK Application: For Precision usages. Super straight Pipes, ...
Product Details
Highlight:
Cold Drawn Seamless Steel Pipe
,BK Seamless Steel Pipe
,5mm Cold Drawn Welded Tubes
Material:
St35, St45, St52
Delivery Condition:
BK,BKW,BKS,GBK,NBK
OD Size:
6-256mm
WT Size:
1-30mm
Straightness:
1/1000 Mm
Product Name:
Cold Drawn Steel Pipe
Production Process:
Cold Drawn
Packing:
Bundles Package
Product Description
Cold Drawn Seamless Steel Pipe
DIN2391 St35/St45/St52 BK Cold Worked Cold Drawn Steel Pipe
O.D. Size: 6-256mm, W.T. Size: 1-30mm, Length: 5.8m/6m Fixed Length, or maximal 11.8m Random Length
Delivery Condition: BK, BKW, BKS, GBK, NBK
Application: For Precision usages.
Super straight Pipes, Straightness: 1/1000mm
Smooth and Clean Inside pipe surface
100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.
| Steel Grade | Chemical Composition | |||||
| Symbol | Material Number |
C Max. |
Si Max. |
Mn |
P Max. |
S Max. |
| ST35 | 1.0308 | 0.17 | 0.35 | ≥0.40 | 0.025 | 0.025 |
| ST45 | 1.0408 | 0.21 | 0.35 | ≥0.40 | 0.025 | 0.025 |
| ST52 | 1.0580 | 0.22 | 0.55 | ≤1.60 | 0.025 | 0.025 |
| Steel Grade | BK | BKW | BKS | |||||
| Name | No. |
Rm Mpa |
A % |
Rm Mpa |
A % |
Rm Mpa |
ReH Mpa |
A % |
| ST35 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 315 | 14 |
| ST45 | 1.0408 | 580 | 5 | 520 | 8 | 520 | 375 | 12 |
| ST52 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 |
| Steel Grade | GBK | NBK | ||||
| Name | No. |
Rm Mpa |
A % |
Rm Mpa |
ReH Mpa |
A % |
| ST35 | 1.0308 | 315 | 25 | 340--470 | 235 | 25 |
| ST45 | 1.0408 | 390 | 21 | 440--570 | 255 | 21 |
| ST52 | 1.0580 | 450 | 22 | 490--630 | 355 | 22 |
Tags: Precision Seamless Steel Pipe, Cold Drawn Steel Pipe, Seamless Steel Pipe, Precision Steel Pipe, DIN2391 Steel Pipe, Precision Cold Drawn Steel Pipe, BK Steel Pipe, Cold Worked Steel Pipe
