Hydraulic And Pneumatic En 10305-4 Seamless Cold Drawn Pipe
Basic Properties
Place of Origin:
China
Brand Name:
New Era
Certification:
ISO9001
Model Number:
EN10305-4
Trading Properties
Minimum Order Quantity:
1 tons
Price:
Negotiation
Payment Terms:
T/T
Supply Ability:
500 tons/month
Product Summary
Hydraulic and Pneumatic Seamless Cold Drawn Pipe EN10305-4Applications:for Auto industry/for machinery use/Oil Cylinder Tube/Motorcycle shock absorber Auto shock absorber inner cylinder/Telescopic Cylinders Size range: O.D.:6-88mm W.T.:1-15mm L:max12000mm Production: Cold Drawn Heat Treatment: +N ...
Product Details
Highlight:
en 10305-4 seamless cold drawn pipe
,Hydraulic seamless cold drawn pipe
,Pneumatic seamless cold drawn pipe
Production Method:
Hydraulic And Pneumatic Seamless Pipes
Delivery Condition:
+N (Normalized)
OD Size:
6-88mm
WT Size:
1-15mm
Steel Material:
E235, E355
Production Process:
Cold Drawn
Application:
For Auto Industry/for Machinery Use/Oil Cylinder Tube/Motorcycle Shock Absorber
Section Shape:
Round
Product Description
Hydraulic and Pneumatic Seamless Cold Drawn Pipe EN10305-4
Applications:
for Auto industry/for machinery use/Oil Cylinder Tube/Motorcycle shock absorber
Auto shock absorber inner cylinder/Telescopic Cylinders
Size range: O.D.:6-88mm W.T.:1-15mm L:max12000mm
Production: Cold Drawn
Heat Treatment: +N (Normailzed), Bright Annealing
Steel Grade and Chemical Compositions:
| Steel Grade | C | Si | Mn | P | S | Al | |
| Steel Name | Steel Number | max | max | max | max | max | min |
| E215 | 1.0212 | 0.10 | 0.05 | 0.70 | 0.025 | 0.025 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 | - |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 | - |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Nubmer | (+Cc) | (+LCc) | (+SR) | (+Ad) | (+N) NBK | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490-630 | 355 | 22 |
Tags: Hydraulic and Pneumatic Steel Pipe, EN10305-4 Hydraulic Steel Pipe, EN10305-4 Steel Pipe, EN10305-4 E235 +N, Steel Pipe, Precision Seamless Steel Pipe, EN10305-4.
