316 304 Thin Wall Seamless Stainless Steel Tubes Small Diameter Round Shape
Basic Properties
Place of Origin:
China
Brand Name:
New-Era
Certification:
ISO9001
Model Number:
ASTM A269
Trading Properties
Minimum Order Quantity:
500kg
Price:
Negotiation
Payment Terms:
T/T
Supply Ability:
300tons per month
Product Summary
Product Description TORICH 316 304 Medical Sanitary Food Grade Pipe Welded Small Diameter Thin Wall Round Seamless Stainless Steel Capillary Tube Standard ASTM A554, A249, A269 and A270, A312 Matrial 201 ( Ni 1.2%), 202 (Ni 3.5%~4.5%), 301(Ni 5%), 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L ...
Product Details
Highlight:
0.5mm Round Stainless Steel Tubes
,Thin Wall Stainless Steel Seamless Pipe
,316 Seamless Stainless Steel Tubes
Keyword:
Stainless Steel Capillary Tube
Surface:
180G, 320G, 400G Satin / Hairline
Material:
201, 202, 304, 316, 316L Etc
OD Size:
0.5mm--8mm
WT Size:
0.08mm - 2mm
Usage:
Medical Chemical Tube
Length:
Max11800mm
Product Description
Product Description
TORICH 316 304 Medical Sanitary Food Grade Pipe Welded Small Diameter Thin Wall Round Seamless Stainless Steel Capillary Tube
| Standard | ASTM A554, A249, A269 and A270, A312 |
| Matrial | 201 ( Ni 1.2%), 202 (Ni 3.5%~4.5%), 301(Ni 5%), 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%), 430 |
| Size | OD: 0.5mm--8mm WT: 0.08mm - 2mm Length: According to Customer's Requirement |
| Surface Finish | 180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish |
| Test and Inspection | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT |
| Application | Decoration construction, upholstery, industry instrument |
Tolerance
a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
