5 - 300mm Dia Bearing Steel Tube , 1 - 30mm Thickness Hydraulic Seamless Pipe

Basic Information

Place of Origin:	China
Brand Name:	New-Era
Certification:	TS16949/ISO9001
Model Number:	SAE52100

Minimum Order Quantity:	500kg
Price:	Negotiation
Packaging Details:	anti-rusty oil,bundles packing with plastic bags wrapped
Delivery Time:	20-30days
Payment Terms:	L/C, T/T
Supply Ability:	2000tons per month

Get Best Price Contact Now

Materials:

GCr.15 100Cr6

Standard:

SAE52100

Size:

Dia 5-300mm Thickness 1-30mm

Plated:

Nickel Or White Or Black

Highlight:

hydraulic seamless pipe

astm seamless pipe

Seamless Bearing Steel Tube for Bearing Ring SAE52100 GCr15 100Cr6

Standard: JIS-SUJ2 GB-GCr15 ASTM A295 DIN-100Cr6
Outer Diameter: 5-329mm
Thickness: 1mm-30mm
Length: 5-12m

The Main Technical Parameter of the finished product

Grade	China	ISO	America	Germany	Japan	England
	GCrl5	1	SAE52100	100Cr6	SUJ-2	S135

Chemical Composition	C	Si	Mn	Cr	p	S	Cu	Ni	MO	[O]
	0.95 ~ 1.05	0.15 ~ 0.35	0.25 ~ 0.45	1.40 ~ 1.65	max 0.025	max 0.025	max 0.02	max 0.02	max 0.10	max 10PPM
Surface Hardness	HB179 ~ 207
Decarbonization Deepth	Outer Surface					Inner Surface
	max0.25mm					max0.25mm
Outside Diameter	φ5m~φ329mm
Wall Thickness	1mm~30mm
Dimensions Tolerance	Outside Diameter		Thickness		Length		Camber		Ellipticity
	+0.4mm -0.00mm		+0.30mm -0.30mm		3~7m		≤1mm/m		≤0.08
