Square / Rectangle Hollow Section Steel Tube ASTM A500 Model For Structural Engineering
Basic Properties
Place of Origin:
China
Brand Name:
New-Era
Certification:
ISO9001
Model Number:
ASTM A500
Trading Properties
Minimum Order Quantity:
1ton
Price:
Negotiation
Payment Terms:
T/T, L/C
Supply Ability:
2000tons per month
Product Summary
Square and Rectangle Hollow Section Seamless Steel Tube ASTM A500 for Structural Engineering Standard: ASTM A500 Steel Rectangle Tubing Cold-Formed Welded and Seamless Carbon Structural Tubes Applications: for construction of bridges, and buildings, and for general strcutrual purposes Size range: O...
Product Details
Highlight:
square section steel tube
,hollow metal tube
Standard:
ASTM A500
Production Process:
Seamless Or Welded
Size:
20-500mm
Shape:
Rectangular,Square,hexagonal
Material:
Grade A, B, C, D
Length:
Maximal 12M
Process:
Cold Drawn
Delivery Time:
45 Days
Product Description
Square and Rectangle Hollow Section Seamless Steel Tube ASTM A500 for Structural Engineering
Standard: ASTM A500 Steel Rectangle Tubing
Cold-Formed Welded and Seamless Carbon Structural Tubes
Applications:
for construction of bridges, and buildings, and for general strcutrual purposes
Size range:
O.D. :20 to 500 mm W.T.:1-30mm L:max12000mm
| Product Name | ASTM A500 Cold-Formed Welded and Seamless Carbon Structural Tubes |
| Material | Grade A, B, C, D |
| Standard | ASTM A500 |
| Application | for construction of bridges, and buildings, and for general strcutrual purposes |
| Certificate | ISO 9001 |
| HS code | 7304319000 |
| Delivery Time | 45 days |
| Packing | Bundles or Wooden Boxes |
| Chemical Reuirement | ||||
| Element | GradeA, B and D | Grade C | ||
| Heat Analysis | Product Analysis | Heat Analysis | Product Analysis | |
| Carbon, max | 0.26 | 0.3 | 0.23 | 0.27 |
| Manganese,max | 1.35 | 1.40 | 1.35 | 1.4 |
| Phosphorus,max | 0.035 | 0.045 | 0.035 | 0.045 |
| Sulfur,max | 0.035 | 0.045 | 0.035 | 0.045 |
| Copper,min | 0.2 | 0.18 | 0.2 | 0.18 |
| Tensil requirements | ||||
| Round Structural Tubing | ||||
| GradeA | Grade B | Grade C | Grade D | |
| Tensil strengths,min,psi(Mpa) | 45 (310) | 58(400) | 62(425) | 58(400) |
| Yield strength,min,psi(Mpa) | 33(230) | 42(290) | 46(315) | 36(250) |
| Elongation in 2 in.(50mm) min,% | 25 | 23 | 21 | 23 |
| Shaped Structural Tubing | ||||
| GradeA | Grade B | Grade C | Grade D | |
| Tensil strengths,min,psi(Mpa) | 45 (310) | 58(400) | 62(425) | 58 |
| Yield strength,min,psi(Mpa) | 39(270) | 46(315) | 50(315) | 36(250) |
| Elongation in 2 in.(50mm) min,% | 25 | 23 | 21 | 23 |
