Place of Origin: | China |
---|---|
Brand Name: | New Era |
Certification: | ISO9001,TS16949 |
Model Number: | ASTM A519 |
Minimum Order Quantity: | 1 tons |
Price: | Negotiation |
Packaging Details: | Bundles Package, Wooden Box Package |
Delivery Time: | 45 days |
Payment Terms: | T/T |
Supply Ability: | 3000 tons/month |
Product Name: | Seamless Mechanical Tubing | Delivery Condition: | HR, CW, SR, A, N |
---|---|---|---|
OD Size: | 6-88mm | WT Size: | 1-15mm |
Material: | 1010, 1020, 1026, 1045, 4130 | Application: | Mechanical Purpose |
Production Process: | Cold Drawn | Advantage: | High Precision |
Highlight: | cold drawn welded tubes,erw welded pipe |
Product Name: 4130 30CrMo Seamless Cold Drawn Steel Tube ASTM A519 , Seamless Mechanical Tubing
Material:1010, 1020, 1026, 1045, 4130, 4140
Size Range: OD: 6-88mm, WT: 1-15mm, Length: 5.8m/6m, maximal 11.8m
Delivery Condition: CW, SR, A, N
Application: For mechanical application
Quality Control:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing or Cold Rolling, On line inspection
5. Heat Treatment: SR, A, N
6. Straightening/Cutting to specified length/Finished Measuring Inspection
7. Quality Testing in own lab with Tensile Strength, Yield Strength, Elongation, Hardness, Straightness, etc.
8. Packing and Stocking.
100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.
Product Name | ASTM A519 4130 Seamless Steel Tubing for Mechaincal Purpose |
Material | 1010, 1020, 1026, 1045, 4130, 4140 |
Delivery Condition | HR, CW, SR, A, N |
Standard | ASTM A519 |
Application | Mechanical usage |
Certificate | TS16949, ISO 9001 |
HS code | 7304319000 |
Delivery Time | 45 days |
Pakcing | Bundles or Woodern Boxes |
Grade | C | Mn | P ≤ | S ≤ | Si | Cr | Mo |
1010 | 0.08--0.13 | 0.30--0.60 | 0.40 | 0.05 | -- | -- | -- |
1020 | 0.18--0.23 | 0.30--0.60 | 0.40 | 0.05 | -- | -- | -- |
1026 | 0.22--0.28 | 0.60--0.90 | 0.40 | 0.05 | -- | -- | -- |
1045 | 0.43--0.50 | 0.60--0.90 | 0.40 | 0.05 | -- | -- | -- |
4130 | 0.28--0.33 | 0.40--0.60 | 0.04 | 0.04 | 0.15--0.35 | 0.80--1.10 | 0.15--0.25 |
4140 | 0.38--0.43 | 0.75--1.00 | 0.04 | 0.04 | 0.15--0.35 | 0.80--1.10 | 0.15--0.25 |
Grade | Condition |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
HRB |
1020 | HR | 345 | 221 | 25 | 55 |
CW | 483 | 414 | 5 | 75 | |
SR | 448 | 345 | 10 | 72 | |
A | 331 | 193 | 30 | 50 | |
N | 379 | 234 | 22 | 60 | |
4130 | HR | 621 | 483 | 20 | 89 |
SR | 724 | 586 | 10 | 95 | |
A | 517 | 379 | 30 | 81 | |
N | 621 | 414 | 20 | 89 |
FAQ:
1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.
2. How about your production capacity?
3000 tons/Month.
3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.
4. Where is your factory?
Jiaxing city, 2 hours away from Shanghai.
5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements
6. How about the minimum order quantity?
Normally for one size above 1 ton.
Welcome to contact us! Thanks.
